Renogy Rover Lite 12V/ 24V/ 36V/ 48V 60A MPPT Solar Charge Controller
- 150V max. solar input offers greater flexibility for DIY projects
- Reliable performance from -31? to 113?with low-temp protection
- Versatile compatibility for 12V to 48V systems and various battery types
- User-friendly design for intuitive operation and smart control
- Certified with a 2-year warranty
More Information
- Rated Battery Input Voltage: Non-Lithium :12VDC / 24 VDC / 36 VDC /48 VDC (Auto Recognition)
- Battery Input Voltage Range: 9VDC~64VDC
- Rated Charge Current: 60A
- Maximum Solar Input Power: 900 W (12V Battery); 1800W (24V Battery); 2000 W (36V Battery); 3200W (48V Battery)
- Maximum Solar Input Voltage (Voc): 150VDC
- Power Consumption: ?15 ma (12V Battery), ?11 ma (24V Battery),?8 ma (36V Battery), ?7 ma (48V Battery)
- MPPT Tracking Efficiency: >99%
- Conversion Efficiency: >97%
- Temperature Compensation: ‘-3mV / ? / 2V (Non-Lithium), ‘0mV / ? / 2V, no compensation (Lithium)
- Charger Algorithm: 3-stage Lead Acid, Bulk, Boost, Float, Equalize* 2-Stage Lithium, Bulk, Boost
- Charger Preset: AGM, Gel, Flooded, Lithium-iron Phosphate, User Custom
GENERAL DATA
- Grounding: Common Negative
- Communication: RS485
- Operating Temperature: ‘-31? -113? /-35 ? – 45?
- Storage Temperature: ‘-40? -176? /-40 ? – 80?
- Humidity: 0%~95% RH
- Cooling: Heat Sink
- Enclosure Rating: IP32
- Dimensions (LxWxH): 305 x 205 x 99 mm / 12.01 x 8.07 x 3.90 inch
- Weight: 3.5 kg /7.71 lb
- Regulatory and Safety Specifications: FCC Path 15, Class B,CE,RoHS
- 2-year material warranty
