Zenec Ze-Rce3701 Camera Barke Light ZE-RCE3701
Image device: 1/4 / 6.4 mm Aptina ASX340AT CMOS sensor Lens focal length: f 1.2 TV system: NTSC / 60 fps Viewing angle: 150 (D) x 130 (H) x 85 (V) Native sensor resolution: 720 (H) x 480 (V) pixels Resolution of video-out: > 420 TV lines Frame rate: 60 fields/sec. Signal to noise ratio: > 48 dB Light sensitivity: 0.3 Lux Video output: 1.0 Vp-p, 75 ohms CVBS White balance: Auto backlight compensation: Auto Gamma correction: 0.45 Gain control: Auto Sync system: Auto Power supply: DC 6 – 24 V Current consumption: 40 mA (DC12V) / 480 mW IP protection rating: IP69K Operating temperature: -30 C ~ +75C, RH 95 % max
Specification
Compatible to the following vehicles:
Fiat Ducato 250/251 as of 2006
Citroen Jumper II 250/250D/250L as of 2006
Peugeot Boxer II 250/251 as of 2006
