Fiamma Carry-Bike Frame 02096-35-
Suitable for Van Conversions for 2 E-bikes or 3 standard bikes New handling for the Carry Bike series Frame: Ducato, Sprinter and Crafter. One Bike carrier and 3 different dedicated frames for each type of vehicle which can be purchased separately. Stainless steel AISI 304 rail support base The geometric configuration of the Carry Bike allows the rear door of the vehicle to be opened even with the bikes mounted Deluxe ladder can be mounted on the left hand door Licence plate carrier with control lighting suggested as optional extra (QQ106394B)
Specification
Item No. 02096-35-
Colour: Aluminium
Vehicle: Van Conversion
Bikes carried standard: 2
Bikes carried max: 3
Max load: 50Kg
E-bike: Yes
Position: Rear double door
Vertical wheel base: N/A
Horizontal wheel base: N/A
Rail type: Rail Plus
Bike block: Pro S1 / Pro S3
Distance between rails: 15cm
Licence plate carrier: Optional extra
Dimensions: N/A
Weight: 9.4Kg
Notes
Replaces QQ106344 to QQ106344E
